Beschreibung
Gelenkwelle
WWE Gelenkwellen mit einseitigem Weitwinkelgelenk
Schlepperseitige Anschlussgabeln und Schutz entsprechend DIN EN 12965
A (Profil) = schlepperseitiger Anschluss
B (Profil) = geräteseitiger Anschluss
Lz (mm)
1210
Baugröße
2380
Profilpaarung
0vGA – 34,5 x 40,0 mm Zitronenprofil Stärke 4,0 mm
1G – 41,0 x 48,0 mm Zitronenprofil Stärke 2,7 mm
Kreuzgelenk
Höhe 75mm
Breite 91mm
Zapfen 2 x 27,0 mm / 2 x 24,0 mm
Schutzausführung
SDF 15Z
Verschluss
QSG/AG
A (Profil)
1 3/8″ (6)
B (Profil)
1 3/8″ (6)
Typ
WWE
